Frame |
6061 Aluminum w/Custom Formed T/T & D/T w/C/S Disc Mount, w/Replaceable Derailleur Hanger |
Fork |
Carbon w/Aluminum Steerer |
Headset |
Threadless 1-1/8”, Zero Stack |
Rims |
Weinmann U26 Disc, 700x32H, Double Wall |
Hubs, Front |
KK Aluminum Disc, QR w/Rubber Seal |
Hubs, Rear |
KK Aluminum Disc, QR w/Rubber Seal, Cassette |
Tires |
Kenda Kwick Bitumen K1068, 700 x 40c |
Spokes |
14G Stainless Black, 32x32 |
Derailleur, Front |
Shimano Acera, FD-T3000, 34.9mm |
Derailleur, Rear |
Shimano Altus, RD-M2000 |
Shifters |
Shimano Altus SL-M2010 9s |
Chain |
KMC Z9 w/MissingLink |
Crankset |
Shimano FC-MT210-2, 46/30T, 2-pc, XS-M: 170, L-XL: 175 |
BB |
Shimano Outboard Cartridge Bearing |
Cassette |
Shimano CS-HG200-9 11-36T, 9-Speed |
Pedals |
Wellgo Platform w/Non-slip Tread, DU Bearings |
Seatpost |
KHS Aluminum Micro-Adjust, 31.6mm |
Saddle |
KHS Ultra Comfort Plus, Soft Shell w/Memory Foam |
Handlebar |
Aluminum Trekking, 630mm, 31.8mm |
Stem |
KHS Aluminum Threadless, 17D, 4-bolt, XS:80mm, S-L: 90mm, XL: 100mm |
Grips |
Q2 Ergo Lock-On, Dual Density |
Brake Levers |
Shimano MT201 |
Brakes |
Shimano MT200 Hydraulic Disc, 160mm Rotors Wave 12 |
Color |
Dark Gray |
Frame Size |
XS/14, S/15.5, M/18, L/20.5, XL/23 |
