Frame |
6061 Aluminum w/Custom Formed T/T & DT with C/S Disc Mount, w/Replaceable Derailleur Hanger, Internal Cable |
Rear Shock |
n/a |
Fork |
SR XCE28, 80mm Travel |
Headset |
Threadless 1-1/8”, ZeroStack |
Rims |
Weinmann XTB26 Aluminum, 700c x 32H, Double wall |
Hubs, Front |
Aluminum Disc w/CNC Rotor Flange, QR |
Hubs, Rear |
Aluminum Disc w/CNC Rotor Flange, QR, Cassette |
Tires |
Kenda Happy Medium, 700 x 40c, 30TPI |
Spokes |
14G Black, 32x32 |
Derailleur, Front |
Shimano FD-TY710, 34.9mm |
Derailleur, Rear |
Shimano Altus M310 |
Shifters |
Shimano SL-M315 Trigger |
Chain |
KMC Z8.3 |
Crankset |
Shimano FC-TY-501, 46/30T, S: 170mm, M-XXL: 175mm |
BB |
Cartridge Bearing |
Cassette |
Shimano CS-HG31-8, 11-34T, 8-Speed |
Pedals |
Resin ATB Platform w/DU Bearings |
Seatpost |
KHS Aluminum Micro-Adjust, 31.6mm |
Saddle |
KHS Sport |
Handlebar |
Aluminum, 31.8mm, 680x20mm |
Stem |
KHS Aluminum Threadless 4-bolt, 6-degree, 31.8mm, S:60mm, M-L:80mm, XL-XXL:90mm, Ladies: S:60mm, M:80mm |
Grips |
KHS Sport Lock-on |
Brake Levers |
Shimano ST-EF500 |
Brakes |
Bengal Cable Disc, MB606, 160mm Rotors Wave ‘12’ w/ABS System |
